Spesifikasi

Pesawat terbang

Weight : 25.4 kg (excl. battery)
         32 kg (incl. battery)
Max Takeoff Weight[1] :
         Max takeoff weight for spraying: 52 kg (at sea level)
         Max takeoff weight for spreading: 58 kg (at sea level)
Max Diagonal Wheelbase : 1925 mm
Dimensions :
         2585×2675×780 mm (arms and propellers unfolded)
         1475×1540×780 mm (arms unfolded and propellers folded)
         1050×690×820 mm (arms and propellers folded)
Hovering Accuracy Range (with strong GNSS signal)
    RTK enabled:
    Horizontal: ±10 cm, Vertical: ±10 cm
    RTK disabled:
    Horizontal: ±60 cm, Vertical: ±30 cm (radar module enabled: ±10 cm)
RTK/GNSSOperating Frequency
    RTK:
    GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
    GNSS:
    GPS L1, BeiDou B1I, GLONASS F1, Galieo E1, QZSS L1
Max Configurable Flight Radius : 2000 m
Max Wind Resistance : 6 m/s

Propulsion System - Motors

Stator Size : 100×28 mm
KV          : 59 rpm/V
Power       : 4600 W/rotor

Propulsion System - Propellers

Material  : Nylon carbon fiber filament
Dimension : 50 inch
Propeller Rotation Diameter : 1270 mm
Quantity  : 4

Dual Atomizing Spraying System - Spray Tank

Material : Plastic (HDPE)
Volume : 20 L
Operating Payload [1] : 20 kg[1]
Quantity : 1

Dual Atomizing Spraying System - Sprinklers

Model : LX8060SZ
Quantity : 2
Nozzle Distance : 1368 mm?Rear Nozzles?
Droplet Size : 50-500 μm
Effective Spray Width[2] : 4-7 m (at a height of 3 m above the crops)

Dual Atomizing Spraying System - Delivery Pumps

Type : Impeller pump (magnetic drive)
Quantity : 2
Single Pump Flow Rate : 0-12 L/min
Max Flow Rate : 16 L/min (2 sprinklers)
                24 L/min (4 sprinklers)

DJI AGRAS T25 Spreading System

Compatible Material Diameter : 0.5-5 mm
Spread Tank Volume : 35 L
Spread Tank Internal Load [10] : 25 kg[1]
Effective Spraying Width : Varies according to material diameter, spinner disk rotational speed, hopper outlet size, and flight altitude. For optimal performance, it is recommended to adjust the corresponding variables to achieve a spreading range of 5-8 meters.

Phased Array Radar System

Model : RD241608RF (forward phased array radar)
        RD241608RB (rear phased array radar)
Terrain Follow : Max slope in mapping-free operation: 50°
                 Altitude detection range: 1-50 m
                 Stabilization working range: 1.5-30 m
Obstacle Avoidance[4] : Obstacle sensing range (multidirectional): 1-50 m

       FOV:
       Forward phased array radar: horizontal 360°, vertical ±45°, upward ±45° (cone)
       Rear phased array radar: vertical 360°, horizontal ±45°
       Working conditions: flying higher than 1.5 m over the obstacle at a horizontal speed no more than 10 m/s and vertical speed no more than 3 m/s.

       Safety limit distance: 2.5 m (distance between the front of propellers and the obstacle after braking)

       Sensing direction: 360° multidirectional sensing

Binocular Vision System

Measurement range : 0.5-29 m
Effective Sensing Speed : ≤10 m/s
FOV : Horizontal: 90°, Vertical: 106°
Operating Environment : Adequate light and discernible surroundings

Remote Controller

Model : RM700B
Operating Frequency[5] : 2.4000-2.4835 GHz, 5.725-5.850 GHz
Max Transmission Distance : 7 km (FCC), 5 km (SRRC), 4 km (MIC/CE)
(unobstructed, free of interference, and at an altitude of 2.5 m)
Wi-Fi Protocol : Wi-Fi 6
Wi-Fi Operating Frequency [5] : 2.4000-2.4835 GHz
                                5.150-5.250 GHz
                                5.725-5.850 GHz
Bluetooth Protocol : Bluetooth 5.1
Bluetooth Operating Frequency
GNSS : GPS+Galileo+BeiDou
Screen : 7.02-in LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m2
Operating Temperature : -20° to 50° C (-4° to 122° F)
Storage Temperature Range :
    Less than one month: -30° to 45° C (-22° to 113° F)
    One to three months: -30° to 35° C (-22° to 95° F)
    Six months to one year: -30° to 30° C (-22° to 86° F)
Charging Temperature : 5° to 40° C (41° to 104° F)
Internal Battery Runtime : 3 hours 18 minutes
External Battery Runtime : 2 hours 42 minutes
Charging Type : It is recommended to use a locally certified USB-C charger at a maximum rated power of 65 W and maximum voltage of 20 V such as the DJI 65W Portable Charger.
Charging Time : 2 hours for internal battery or internal and external battery (when remote controller is powered off and using a standard DJI charger)

DB800 Intelligent Flight Battery

Model : DB800 Intelligent Flight Battery
        (BAX702-15500mAh-52.22V)
Weight : Approx. 6.6 kg
Capacity : 15500 mAh
Nominal Voltage : 52.22 V

D6000i Multifunctional Inverter Generator

Output Channel : 1. DC charging output 42-59.92V/4500W
                 2.AC output 230V/1500W or 120V/750W[8]
Battery Charging Time[11] : To fully charge one battery (DB800 battery) takes 9-12 mins
Fuel Tank Capacity : 20 L
Starting Method : Starting the Generator via the One-Button Start Switch
Max Power of Engine : 6000 W
Fuel Type : Unleaded gasoline with RON ≥91 (AKI ≥87) and alcohol content less than 10%(*Brazil: unleaded gasoline with RON ≥ 91 and alcohol content of 27%)
Reference Fuel Consumption [9] : 600 ml/kWh
Engine Oil Model : SJ10W-40

C8000 Intelligent Charger

Model Number : CHX101-7000
Dimensions : 300 × 280 × 230 mm
Weight : Approx. 11.5 kg
Input/Output :
    Input Voltage: 100-240 VAC
    Output Voltage: 59.92V
    Output Current: 100A max
Charging Time[11] : Fully charges a battery in 9 to 12 minutes (DB800 Intelligent Flight Battery)
Protection Functions : Over-temperature, over-voltage, under-voltage, short-circuit, and fan stall protection
Charging Safety : AC wire protection, power wire protection, and charge connector protection
